Main Features
*Automatic shutdown function and low power design of software and hardware of the instrument with long working hours, suitable for field use.
*The surface roughness of metal and non-metallic.
*Pocket-size & economically price
*Large measuring range suitable for most materials
*Optimized electric circuit design with transducer structure-design, high integrate power.
*It could test ex-circle, flat surface, conical surface and also test groove larger than 80*30mm.
Technical Parameters
|
|
KS-300 |
KS-310 |
|
Testing parameters |
Ra, Rz |
Ra, Rz, Rq, Rt |
|
Measuring range (um) |
Ra: 0.05-15.0 Rz: 0.1-50.0 |
Ra, Rq: 0.05-15.0 Rz, Rt : 0.1-50.0 |
|
Sample length (mm) |
0.25, 0.80, 2.50 |
|
|
Evaluation length(mm) |
1.25, 4.0, 5.0 |
|
|
Stroke length (mm) |
6 |
|
|
Indication accuracy |
0.01 |
|
|
Indication error |
±(7-10)% |
|
|
Variability |
<12% |
|
|
Power |
Rechargeable li-battery |
|
|
Stylus static force: |
≤ 0.016N |
|
|
Force measuring |
≤ 800N/m |
|
|
Working temperature |
-20℃～40℃ |
|
|
Relative humidity |
<90% |
|
|
Weight of Host |
200g |
|
|
Size |
106mmx70mmx24mm |
|
